NMB Cooling Fan 2410VL-S5W-B59

Model Number: 2410VL-S5W-B59 (or 2410VL-05W-B59)
Dimensions: \(60 \times 60 \times 25 \text{mm}\)
Voltage: 24V DC (Operating range usually \(\sim 10\text{V}\)–\(27\text{V}\))
Current: 0.11A (approx. 2.64W)
Speed: \(3500 \text{RPM}\) – \(4200 \text{RPM}\)
Airflow: \(\sim 22.8\) CFM
Noise Level: \(\sim 35 \text{dB}\)
Wire Type: 3-wire (typically red, black, and a white or yellow tachometer signal wire for monitoring)
Bearing Type: Dual Ball Bearing
Connector: 3-pin connector common in industrial equipment (e.g.,

Category: Fan
